ACQ80 Drives for Solar Pump

Get a Price/Quote

MOQ : 1 Nos

ACQ80 Drives for Solar Pump Specification

Power Factor
>=0.98

Operating Temperature
-10C to +50C

Surface Finish
Matte

Efficiency
>=97%

Shape
Rectangular

IP Rating
IP21

Overheating Protection
YES

Connector Type
Screw Terminal

Feature
Intelligent MPPT, Energy Efficient, Auto Restart

Humidity %
0-95% non-condensing

Mounting Type
Wall Mounted

Insulation Material
High-Grade Plastic

Product Type
ACQ80 Drive for Solar Pump

Application
Solar Water Pumping Systems

Protection Level
Overload, Short Circuit, Motor Phase Loss

Frequency (MHz)
50/60 Hz

Rated Voltage
415 V

Energy Consumption
Low

Output Type
Three-Phase Output

Color
Grey

Dimension (L*W*H)
278 x 188 x 195 mm

Weight
7.2 kg

Size
Standard

Input Voltage
380-480 V AC

Phase
Three Phase

Connection Type
Screw Terminal

No Of Poles
3

Material
ABS Plastic & Metal

Cooling Method
Fan Cooled

Communication Interface
RS-485 Modbus Supported

Compliance
CE, ISO 9001 Certified

Maximum Output Current
18A

Motor Compatibility
IEC & NEMA Standards

Digital Display
Integrated LCD Display

Alarm Functions
Over Voltage, Under Voltage, Overload, Phase Failure

Braking Unit
Built-in Dynamic Braking

Start-up Torque
180% at 0.5Hz

Input Phase
Three Phase

Control Method
V/F (Voltage/Frequency) and Sensorless Vector Control

ACQ80 Drives for Solar Pump Trade Information

Minimum Order Quantity
1 Nos

Main Domestic Market
Rajasthan

About ACQ80 Drives for Solar Pump

Experience peerless efficiency and enviable performance with the popular ACQ80 Drives for Solar Pump, now available at clearance sale prices. Designed for commercial and industrial solar water pumping systems, this incomparably reliable drive combines advanced V/F and sensorless vector control for optimal operation. The integrated LCD digital display ensures precise monitoring, while CE and ISO 9001 certifications guarantee superior quality. Energy consumption is low, featuring intelligent MPPT, auto restart, and dynamic braking. With rated voltage of 415V, robust protection levels, and a matte, standard-sized finish, ACQ80 drives define the standard for trusted, energy-efficient pump controllers.

Commercial Excellence & Competitive Edge

ACQ80 Drives for Solar Pump deliver outstanding reliability in commercial operations, thanks to extra features like intelligent MPPT, dynamic braking, and auto restart. With integrated LCD displays and support for RS-485 Modbus, users gain superior control and real-time system data. Built to IEC and NEMA standards, ACQ80 boasts enviable protection levels and a high efficiency rating. These drives remain the preferred choice for businesses seeking sustainable and peerless performance in solar water pumping applications.

Global Market Presence & Fast Delivery

ACQ80 Drives enjoy robust demand in prominent export markets across Asia, Africa, and the Middle East, while also being a popular solution in major domestic regions. Upon purchase order confirmation, manufacturers ensure swift order completion and meticulous dispatching to guarantee fast delivery times. Efficient logistics and comprehensive support enable seamless distribution, making ACQ80 Drives the first choice for both distributors and large-scale end users seeking high performance with timely fulfillment.

FAQs of ACQ80 Drives for Solar Pump:

Q: How does the ACQ80 Drive optimize solar water pump efficiency?

A: ACQ80 Drives utilize sensorless vector control and intelligent MPPT technology to maximize energy efficiency, providing high output and stable operation even in fluctuating solar input conditions.

Q: What is the process for installing the ACQ80 Drive?

A: Installation requires securing the drive to a wall mount, connecting via screw terminals, and configuring settings through the integrated LCD display. Professional support and detailed user manuals are provided for ease of setup.

Q: What competitive advantages does the ACQ80 offer?

A: The ACQ80 Drive boasts competitive advantages such as built-in dynamic braking, advanced overload and short-circuit protection, CE and ISO 9001 certification, and compatibility with IEC & NEMA standard motors.

Q: When can customers expect order fulfillment and shipping?

A: Dispatching of ACQ80 Drives typically occurs promptly after purchase order and order completion, with fast delivery assured through streamlined logistics networks for both domestic and international destinations.

Q: Where is the ACQ80 Drive commonly used?

A: ACQ80 Drives are widely used in commercial, agricultural, and industrial solar water pumping systems where reliable, energy-efficient control is essential.

Q: What is the benefit of RS-485 Modbus support in ACQ80 Drives?

A: RS-485 Modbus support enables seamless communication and integration with automation systems, allowing remote monitoring and control for enhanced operational flexibility.
